Functions and Features:

1. DC permanent magnet synchronous motor (PMSM) and servo control technology.

2. The motor has the same performance as the main motor of the CNC machine and electric vehicle. It has high control precision, high torque density, good torque balance, low power consumption, high efficiency, and low noise.

3. Double extension spring crank transmission design, for a more stable and reliable structure.

4. Reasonable balance design makes less dependence on spring and easier adjustment and less maintenance.

5. No limit switch design, accurate encoder detection, detecting boom position when power on.

6. Manual clutch design: When power-off, open the manual hand-wheel clutch to move or lock the boom at any position by hand directly. (patented technology)

7. More sensitive and reacting faster when reversing on obstacles.

8. More than 95% of the parts are precisely manufactured by the flexible production line of industrial robots. Higher assembly precision and better batch consistency bring longer product service life.

9. Bi-direction boom holder design, left-installation, and right-installation can be exchanged easily and quickly.

10. 4-digit digital tube display, easy to set motor speed, counting, and auto-reversing sensitivity.

11. A network port, loop detector, and radar module can be added.

12. Alarm against abnormal lifting boom.

13. The DC12V power supply is optional.

Technical data:

1.Working Temperature: -35℃~+85℃

2. Input Voltage: 220VAC±10%, 110VAC±10%

3. Max Motor Power: 150W

4. Humidity: ≤90%

5. The distance of Remote Control: ≥30m

6. Insulation Grade: F

7. Running Speed and Max Boom Length:

CB01SV-H: 1/1.5/2S, max boom length: 4m straight boom

CB01SV-I: 3/4/5S, max boom length: 6m straight boom, 4.5m two-fence boom, 4m three-fence boom.
